產品特性
? 玻璃鈍化芯片
? 在10/1000μ波形重復率（占空比）：0.01%下，峰值脈沖功率可達1000w
? 低漏電流
? 單、雙向單元
? 優(yōu)良的鉗位能力
? 快速的響應時間
? 通過無鉛認證，符合ROHS
機械參數(shù)
? 方法：模制塑料
? 環(huán)氧樹脂：UL 94V-0阻燃劑
? 引線：可焊性按MIL-STD-750，方法2026可焊
? 極性：除雙極性外有色帶的一端為陰極
? 安裝位置：任何
| 型號 | 圖片 | 封裝 | VBR.MIN(V) | VBR.MAX(V) | IT(mA) | IR(μA) | VRWM(V) | IPP(A) | VC(V) | 下載 |
|---|---|---|---|---|---|---|---|---|---|---|
|
SMB/DO-214AA |
6.40 |
7.00 |
10 |
800 |
5.0 |
108.70 |
9.2 |
|
|
|
SMB/DO-214AA |
6.67 |
7.37 |
10 |
800 |
6.0 |
97.09 |
10.3 |
|
|
|
SMB/DO-214AA |
7.22 |
7.98 |
10 |
500 |
6.5 |
89.29 |
11.2 |
|
|
|
SMB/DO-214AA |
7.78 |
8.60 |
10 |
200 |
7.0 |
83.33 |
12.0 |
|
|
|
SMB/DO-214AA |
8.33 |
9.21 |
1 |
100 |
7.5 |
77.52 |
12.9 |
|
|
|
SMB/DO-214AA |
8.89 |
9.83 |
1 |
50 |
8.0 |
73.53 |
13.6 |
|
|
|
SMB/DO-214AA |
9.44 |
10.40 |
1 |
10 |
8.5 |
69.44 |
14.4 |
|
|
|
SMB/DO-214AA |
10.00 |
11.10 |
1 |
5.0 |
9.0 |
64.94 |
15.4 |
|
|
|
SMB/DO-214AA |
11.10 |
12.30 |
1 |
5.0 |
10.0 |
58.82 |
17.0 |
|
|
|
SMB/DO-214AA |
12.20 |
13.50 |
1 |
5.0 |
11.0 |
54.95 |
18.2 |
|
|
|
SMB/DO-214AA |
13.30 |
14.70 |
1 |
5.0 |
12.0 |
50.25 |
19.9 |
|
|
|
SMB/DO-214AA |
14.40 |
15.90 |
1 |
1.0 |
13.0 |
46.51 |
21.5 |
|
|
|
SMB/DO-214AA |
15.60 |
17.20 |
1 |
1.0 |
14.0 |
43.10 |
23.2 |
|
|
|
SMB/DO-214AA |
16.70 |
18.50 |
1 |
1.0 |
15.0 |
40.98 |
24.4 |
|
|
|
SMB/DO-214AA |
17.80 |
19.70 |
1 |
1.0 |
16.0 |
38.46 |
26.0 |
|
|
|
SMB/DO-214AA |
18.90 |
20.90 |
1 |
1.0 |
17.0 |
36.23 |
27.6 |
|
|
|
SMB/DO-214AA |
20.00 |
22.10 |
1 |
1.0 |
18.0 |
34.25 |
29.2 |
|
|
|
SMB/DO-214AA |
21.10 |
23.30 |
1 |
1.0 |
19.0 |
32.49 |
30.8 |
|
|
|
SMB/DO-214AA |
22.20 |
24.50 |
1 |
1.0 |
20.0 |
30.86 |
32.4 |
|
|
|
SMB/DO-214AA |
24.40 |
26.90 |
1 |
1.0 |
22.0 |
28.17 |
35.5 |
|
|
|
SMB/DO-214AA |
26.70 |
29.50 |
1 |
1.0 |
24.0 |
25.71 |
38.9 |
|
|
|
SMB/DO-214AA |
28.90 |
31.90 |
1 |
1.0 |
26.0 |
23.75 |
42.1 |
|
|
|
SMB/DO-214AA |
31.10 |
34.40 |
1 |
1.0 |
28.0 |
22.03 |
45.4 |
|
|
|
SMB/DO-214AA |
33.30 |
36.80 |
1 |
1.0 |
30.0 |
20.66 |
48.4 |
|
|
|
SMB/DO-214AA |
36.70 |
40.60 |
1 |
1.0 |
33.0 |
18.76 |
53.3 |
|
|
|
SMB/DO-214AA |
40.00 |
44.20 |
1 |
1.0 |
36.0 |
17.21 |
58.1 |
|
|
|
SMB/DO-214AA |
44.40 |
49.10 |
1 |
1.0 |
40.0 |
15.50 |
64.5 |
|
|
|
SMB/DO-214AA |
47.80 |
52.80 |
1 |
1.0 |
43.0 |
14.41 |
69.4 |
|
|
|
SMB/DO-214AA |
50.00 |
55.30 |
1 |
1.0 |
45.0 |
13.76 |
72.7 |
|
|
|
SMB/DO-214AA |
53.30 |
58.90 |
1 |
1.0 |
48.0 |
12.92 |
77.4 |
|
|
|
SMB/DO-214AA |
56.70 |
62.70 |
1 |
1.0 |
51.0 |
12.14 |
82.4 |
|
|
|
SMB/DO-214AA |
60.00 |
66.30 |
1 |
1.0 |
54.0 |
11.48 |
87.1 |
|
|
|
SMB/DO-214AA |
64.40 |
71.20 |
1 |
1.0 |
58.0 |
10.68 |
93.6 |
|
|
|
SMB/DO-214AA |
66.70 |
73.70 |
1 |
1.0 |
60.0 |
10.33 |
96.8 |
|
|
|
SMB/DO-214AA |
71.10 |
78.60 |
1 |
1.0 |
64.0 |
9.71 |
103.0 |
|
|
|
SMB/DO-214AA |
77.80 |
86.00 |
1 |
1.0 |
70.0 |
8.85 |
113.0 |
|
|
|
SMB/DO-214AA |
83.30 |
92.10 |
1 |
1.0 |
75.0 |
8.26 |
121.0 |
|
|
|
SMB/DO-214AA |
86.70 |
95.80 |
1 |
1.0 |
78.0 |
7.94 |
126.0 |
|
|
|
SMB/DO-214AA |
88.80 |
97.60 |
1 |
1.0 |
80.0 |
7.72 |
129.6 |
|
|
|
SMB/DO-214AA |
94.40 |
104.00 |
1 |
1.0 |
85.0 |
7.30 |
137.0 |
|
